| NO. | Item name | Parameters | |
| 1 | Machining range | H-beam | Section height H: 150-1000mm Flange width B: 75 ～ 500mm |
| Maximum thickness of material | 60mm | ||
| 2 | Drilling power box | Quantity | 3 |
| Max. drilling diameter | Cemented carbide ￠ 30mm High speed steel ￠ 40mm | ||
| Spindle taper hole | BT40 | ||
| Spindle motor power | 3×11KW | ||
| Spindle speed (stepless speed regulation) | 0～2000r/min | ||
| 3 | CNC axis | Quantity | 7 |
| Servo motor power of fixed side, moving side and middle side feed shaft | 3×2KW | ||
| Fixed side, moving side, middle side, moving side positioning axis servo motor power | 3×1.5KW | ||
| Moving speed of three positioning CNC axes | 0～10m/min | ||
| Moving speed of three feed CNC axes | 0～5m/min | ||
| Width detection stroke | 900mm | ||
| Web detection stroke | 290mm | ||
| 4 | Feeding trolley | Feeding trolley servo motor power | 5 KW |
| Maximum feeding speed | 20m/min | ||
| Maximum feeding weight | 8T | ||
| 5 | Spray cooling system | Number of nozzles | 1 |
| 6 | Compressed air pressure | 0.5Mpa | |
| 7 | Cooling mode | Internal cooling + external cooling | |
| 8 | Dimension of main machine (L x W x H) | About 5.6×1.6×3.3m | |
| 9 | Machine weight | About 7000Kg | |
5 In order to meet the processing of multiple hole diameters, the machine is equipped with three in-line tool magazine, each unit is equipped with a tool magazine, and each tool magazine is equipped with four tool positions. 6 The machine is equipped with material width detection and web height detection device, which can effectively compensate the deformation of the material and ensure the machining accuracy; 7 The machine adopts the trolley feeding, and the CNC clamp feeding mechanism. 8 Each spindle box is equipped with its own external cooling nozzle and internal cooling joint, which can be selected according to the needs of drilling.| NO. | Name | Brand | Country |
| 1 | Spindle | Kenturn | Taiwan, China |
| 2 | Linear rolling guide rail pair | HIWIN/CSK | Taiwan, China |
| 3 | Hydraulic pump | Justmark | Taiwan, China |
| 4 | Solenoid hydraulic valve | ATOS/Yuken | Italy / Japan |
| 5 | Servo motor | Siemens / MITSUBISHI | Germany / Japan |
